New design customized metal seamless rain gutter cold roll forming
machine
Product Description
1. Material: 1) Suitable Coil Thickness: 1mm 2) Suitable Raw
Material: Galvanized steel sheet 2. The equipment including Roll
forming machine 1 set Electrical control system 1 set Hydraulic
system 1 set Hydraulic de-coiler 1 set Max. loading 3-5 T
Manual decoiler Single - head de-coiler, unilateral discharge Using
electric pressure internal intensify Max. loading weight : 3-5tons
Main roll forming machine Main engine power: 15KW Structure: Welded
plate Drive: Gearbox driving Spindle diameter: Φ80mm, Material :
Gcr12 quenching and tempering treatment Roller material: GCR12
Quenching to 58°-62°, Surface plating treatment Stations: About
5-10 stations The unit adopts frequency conversion 8m-15m/min
(excluding punching time) Computer PLC control, operation panel
with touch screen display
Specifications
| Model |
GWC127 | Note |
| Material spec | Color plate, galvalume plate, aluminum plate and cooper plate | This machine is customizable upon each customer's requirements and
the characteristics of processed material. |
| Feeding width | 310mm |
| Processing thickness | 0.3-0.8mm |
| Roller material | 45# steel coated with hard chrome |
| Main motor power / hydraulic station power | 7.5kW / 5.5kW | These parameters can be set according to the required production
capacity. |
| Forming passes | 16 |
| Forming speed | 5-15 meters/minute |
| Machine dimensions | 11×1.0×1.0m |
| Machine weight | 8T |
Features of this Galvanized Drywall Used Omega Profile Light Gauge
Steel Framing Cold Roll Forming Machine
- lower cost
- high efficiency
- reliable working
- low energy consumption
Components of the Galvanized Drywall Used Omega Profile Light Gauge
Steel Framing Cold Roll Forming Machine
1. Steel strip supporting frame
2. Feeding platform
3. Automatic shearing system
4. Hydraulic system
5. Steel strip unfolding system
6. Computer control system (imported computer)
7. High-precision automatic counter
8. Receiving table
Optional components of the Galvanized Drywall Used Omega Profile
Light Gauge Steel Framing Cold Roll Forming Machine
Manual uncoiler frame in different tons
Hydraulic automatic uncoiler
Working space and workman for the Galvanized Drywall Used Omega
Profile Light Gauge Steel Framing Cold Roll Forming Machine :
1. Ground-level land
2. ≥5T overhead travelling crane
3. Space for storing the material
4. Space for laying the machine
5. Road for vehicle moving
6. Workman: 2, operator and porter
Rain Gutter Roll Forming Machine
The rain gutter roll forming machine can be designed according to
the drawings and requirements provided by our client. It is used to
fabricate rain gutters that could work together with down pipes to
form the drainage system for the building.
Processing Flow
Passive decoiling →guided material feeding → roll forming →
cut-to-length → offloading
Payment terms and after-sale service: 1) FOB Tianjin 2) Payment: 30% T/T deposit, and pay the balance
before shipping. 3) Delivery time: 50 working days. 4) Guarantee
period: 12 months limited warranty starting from date of delivery.
Shipping cost for parts to be replaced during warranty period have
to be borne by the customer. 5) Spare parts: bearings, buttons,
chains, magnetic valve, protective tube etc. 6) Installation and
training: 1. If buyers visit our factory and check the machine, we
will teach you how to install and us the machine, and also train
your workers/technician face to face. 2. Without visiting, we will
send you user manual or video to teach you to install and operate.
3. COST OF INSTALLATION: The buyer should pay the installation
charges (USD 100 one man one day). To the seller's appointed
account by T/T before the seller's technicians go to the buyer's
factory. The buyer pays the seller's technicians travel cost
outside China, including round air tickets fee, accommodation and
food, provide transportation from living hotel to the work place,
necessary communication, and insurance, etc.
